Maximum operator comfort and control ensures the Cat® 140 motor grader optimizes performance, especially on long work days. Its fuel efficient C7 engine includes protection technologies and delivers the power needed for precise control and more work completed per hour.
Net Power Range (Tier 3)
136kW
Displacement
7.2l
Bore
110mm
Overview
Designed for maximum operator comfort, the Cat® 140 optimizes operational efficiency and productivity. Get the work done with the 140 Motor graders. With ease of operation and service, get the most out of your investment to build and maintain roads.
Specifications
Engine
- Net Power Range (Tier 3)136kW
- Displacement7.2l
- Bore110mm
- Stroke127mm
- Maximum Torque - VHP Plus1052N·m
- Derating Altitude3048m
- Standard - Ambient Capability43°C
- High - Ambient Capability50°C
Overview
BETTER COMFORT AND CONTROL
<ul><li>Visibility is key to your safety, efficiency and quality of work. The 140 (12M) delivers with angled cab doors, tapered engine enclosure and a sloped rear window make it easy to see the moldboard and tires, as well as behind the machine. Optional rear camera further enhances lines of sight.</li><li>The most spacious, comfortable cab in the industry.</li><li>Joystick controls reduce hand and arm movement by 78%, which helps to lowers operator fatigue.</li><li>Easy-reach rocker and control switches</li><li>Standard Cat Comfort Series suspension seat.</li><li>Control pods adjust electronically - easy to set ideal operating position.</li><li>Isolation mounts reduce sound and vibration for more relaxed environment.</li><li>High capacity Heating, Ventilation and Air Conditioning (HVAC) system dehumidifies and pressurizes the cab, circulates fresh air, seals out dust and keeps windows clear.</li><li>Optional deluxe radio with CD features MP3 and Bluetooth technology.</li><li>In-dash instrument cluster houses easily read, high-visibility gauges and warning lamps keep you aware of critical system information.</li><li>Two electro-hydraulic joysticks make operation easy and comfortable. Adjustable control pods ensure they are positioned for optimal comfort, visibility and operation.</li><li>Joystick Functions:</li></ul><ol><li>Left joystick controls steering, articulation, return-to-center, wheel lean, gear selection, left moldboard lift cylinder and float.</li><li>Right joystick controls drawbar, circle and moldboard functions as well as electronic throttle control and manual differential lock/unlock. Joystick lean angle mirrors the steer tires' turning angle.</li></ol><ul><li>Brake tensioning system holds the joystick in position until the operator moves it.</li><li>Steering control automatically reduces steering sensitivity at higher ground speeds for predictable control.</li><li>Infinitely variable roller switches control the rear ripper and/or front lift group (when equipped).</li><li>Electronic Throttle Control improves productivity providing the best match of power and torque for the demands of each application.</li><li>Articulation Return-to-Center automatically returns the machine to a straight frame position from any angle with the touch of a button.</li></ul>
Attachments
COMPATIBLE WITH
Cat® Detect with Smart Camera
The Cat® Detect with Smart Camera safety technology utilizes a smart camera, an in-cab display and alerts to help your operator keep track of people near the machine.
View ModelsCat® Detect with Surround Cameras
The Cat® Detect with Surround Camera system uses three or four cameras and an in-cab display to give operators a view of their surroundings. It's an effective way to increase safety at the site.
View ModelsCat Grade with Cross Slope for Motor Graders
Cat® Grade with Cross Slope is an integrated system that enables operators to achieve grade faster and more accurately by automating the cross slope of the blade, allowing the operator to do more in the same amount of time.
View Models
