Operator comfort, smart systems and respected Cat construction help make the Cat 120 and 120 All-Wheel Drive (AWD) motor graders leaders in their class. With technologies to speed and enhance grading performance, this machine is ready to tackle your needs.
Net Power Range (Tier 3)
97kW
Derating Altitude (AWD)
1676m
Maximum Torque - ISO 9249
822N·m
Overview
The Next Generation Cat® 120 motor grader offers the options of joystick or steering wheel and lever controls with the all-wheel drive option. Save up to 15 percent in fuel consumption. Cab and comfort options help improve performance. Factory integrated technology, such as Cat Grade with Cross Slope and Stable Blade options ensure grade for any project.
Specifications
Engine
- Net Power Range (Tier 3)97kW
- Derating Altitude (AWD)1676m
- Maximum Torque - ISO 9249822N·m
- Derating Altitude3000m
- Maximum Torque - AWD On828N·m
- All-Wheel Drive Net Power Range (Tier 3)101kW
- Bore105mm
- Displacement7.01l
- Stroke135mm
- Standard Capability50°C
Overview
BUILT TO PERFORM
<ul> <li>Get to work with balanced weight and power in the Cat C7.1 engine.</li> <li>Increase your fuel economy up to 15% with the standard Eco mode.</li> <li>Cat Grade technology helps you get to the target grade in fewer passes.</li> <li>The powershift transmission works hard with machine balance to ensure drawbar power to the ground.</li> <li>Powertrain components are specifically made to be rebuilt.</li> </ul>
Attachments
COMPATIBLE WITH
Cat® Detect with Smart Camera
The Cat® Detect with Smart Camera safety technology utilizes a smart camera, an in-cab display and alerts to help your operator keep track of people near the machine.
View ModelsCat® Detect with Surround Cameras
The Cat® Detect with Surround Camera system uses three or four cameras and an in-cab display to give operators a view of their surroundings. It's an effective way to increase safety at the site.
View ModelsCat Grade with Cross Slope for Motor Graders
Cat® Grade with Cross Slope is an integrated system that enables operators to achieve grade faster and more accurately by automating the cross slope of the blade, allowing the operator to do more in the same amount of time.
View Models
